Dream Star
Ref.: MR-012EAN: 3700755645620
This product is no longer in the M.RED catalogue. Its specifications and datasheet are kept here for owners.
Tech specs
Datasheet (PDF, English)References1
- Serie Model
- None
Dimensions & Weight10
- Height
- 458 mm
- Width
- 180 mm
- Length
- 302 mm
- Net Weight
- 5.7 Kg
- Volume
- 24.9 L
- Box height
- 530 mm
- Box width
- 260 mm
- Box length
- 380 mm
- Gross weight
- 6.6 Kg
- Gross volume
- 52.36 L
Design16
- Usage
- Gaming
- Form Factor
- Mini Tower
- Color
- Dark Grey
- Raw Materials
- Steel, ABS Plastic
- Mred Cover
- Yes
- Window Right Side Panel
- No
- Window Left Side Panel
- No
- LED Lights
- Yes
- LED Type
- ARGB
- Motherboard LED Compatibility Brands
- Asus, Msi
- ARGB Compatibility
- Yes
- Side Bar LED Qty
- Yes
- LED Controler
- Yes
- LED Controler Operation Mode
- Stand alone
- Controler IRDA Remote Control
- Yes
- Front panel wireless connectors
- No
Conception7
- Dust Filters Qty
- 6
- Top Dust Filter
- Yes
- Front Dust Filter
- Yes
- Bottom Dust Filter
- Yes
- Removable Front Panel
- Yes
- Replaceable Front Panel
- No
- Removable Right Side Panel
- Yes
Compatibility & Clearance9
- Clearance Max. CPU Cooler
- 130 mm
- Motherboard Support
- Micro ATX, Mini-ITX
- Vertical VGA Extension Slots
- No
- Clearance Max. Vertical Graphic Card
- 320
- Thickness Max. carte Vertical Graphic Card
- 60
- Front Fan and Radiator Clearance
- 25
- Top Fan and Radiator Clearance
- 25
- Supported PSU Type
- ATX, SFX
- PSU Max Length
- 140 mm
Cooling9
- Pre-Installed Fans - Front
- 2*120 ARGB
- Pre-Installed Fans - Rear
- 1*120 ARGB
- Fan Support - Front
- 2*120, 2*140
- Fan Support - Top
- 1*80
- Fan Support - Side
- 2*120, 2*140
- Fan Support - Bottom
- 1*120, 1*140
- Fan Support - Rear
- 1*120, 1*140
- Watercooling System Support
- Yes
- Radiator Support - Side
- 240, 280
Extension slots6
- Horizontal PCI Slot Qty
- 3
- Vertical PCI Slot Qty
- 0
- Horizontal VGA support
- No
- 2,5" Drive Bays Qty
- ?
- 3,5" Drive Bays Qty
- ?
- HDD removable rack
- ?
Connectivity7
- Connectors Location
- Top
- USB 2.0
- 0
- USB 3.0
- 2
- USB 3.2 Gen 2 Type-C
- 1
- 3.5mm Headset Jack (Audio+Mic)
- 1
- 3.5mm Headset Jack (Audio)
- 0
- 3.5mm Headset Jack (Mic)
- 0
Warranty & Docs1
- Commercial Warranty
- 2 années
